PETROL TEST FACILITY, NO DIESEL
Hose & Clip Kit For 4 Cylinder Engines Fitted With Very Early Bosch D Jetronic Series 0280150--- Injectors - Kit 94
Hose & Clip Kit For 4 Cylinder Engines Fitted With Very Early Bosch D Jetronic Series 0280150--- Injectors - Kit 94
300 in stock
Couldn't load pickup availability
This kit was designed to suit very early series Bosch EV1 D Jetronic type injectors with a single arrow headed inlet port, requiring hose clip clamping at both ends of the hose pieces (not the double arrow headed ferrule fixing).
Please refer to the additional photo to identify the single arrow headed inlet pipe type.
The kit contains our Aramid reinforced, ethanol-resistant fuel hose and hose clips, enabling you to upgrade your old polyester injector hoses at home, futureproofing your classic vehicle.
⚠️ Why You Must Replace Your Old Fuel Hoses Now
UK fuel now contains up to 10% ethanol. Older polyester-reinforced hoses are not ethanol-resistant — they degrade from the inside out, becoming brittle and prone to cracking. A leaking fuel hose near a hot engine is a fire risk.
Don’t just replace the injector hoses — check and replace all hoses from the tank to the feed and return lines.
Contents
Kit 94 contains:
4 x Aramid reinforced, ethanol-resistant hose cut to your requirement (up to 52mm in length each), longer hose available at additional cost if required
8 x Fuel line clips, matched perfectly to our hose
Terms
The injector in the photo is not included in the sale, it is there to help you identify the kit.
About the Hose Included in This Kit
All Mr Injector UK kits use Cohline aramid-braided fuel hose — the same hose used in aerospace and aviation applications.
· Construction: FPM inner tube, ECO rubber intermediate layer, braided aramid fibre reinforcement, ECO rubber outer cover
· Working pressure: 10 bar | Bursting pressure: 50 bar
· Temperature: -40°C to +125°C (up to +150°C for short periods)
· Meets multiple international standards: DIN 73379-B1, SAE J30R9, BMW GS 93010, DBL 6256.70, GME 08 007, VW TL 524 24 — providing superior resistance to degradation and fuel permeation compared to standard hoses
· 100% ethanol resistant — suitable for E10 fuel, bio-diesel (RME), and all commercially available fuels
· Classic vehicle compatible
All kits and parts orders dispatched by Master Injector UK.
Share
Because of the delicate nature of injectors, particularly historic hose ones, we advise using somebody competent in removing/installing the parts for you to prevent issues arising such as over-tightening of the hose clamps or damaging the pintle needles. Doing so yourself is at your own risk and we take no responsibility for damage resulting from poor handling or installation of parts.
